Name: Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room
Brand: Guangdong Air Giant Fire Equipment Co.,Ltd.
SKU: QMP32/2.5, QMP40/4.2, QMP52/2.5, QMP70/4.2, QMP100/4.2, QMP106/2.5, QMP120/4.2, QMP147/2.5, QMP150/4.2, QMP180/2.5, QMP180/4.2
Availability: InStock

Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room

1 set

MOQ

negotiation

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Model No.: QMP32/2.5, QMP40/4.2, QMP52/2.5, QMP70/4.2, QMP100/4.2, QMP106/2.5, QMP120/4.2, QMP147/2.5, QMP150/4.2, QMP180/2.5, QMP180/4.2

Volume (L): 32，40，52， 70, 100，106，120, 147，150, 180

Storage Pressure: 4.2MPa;2.5Mpa

Internal Diameter: 300, 350, 400

Color: Red

Basic Infomation

Place of Origin: China

Brand Name: Air Giant

Certification: CAL,CMA,CNAS,ILAC-MRA,CCC

Model Number: QMP32/2.5, QMP40/4.2, QMP52/2.5, QMP70/4.2, QMP100/4.2, QMP106/2.5, QMP120/4.2, QMP147/2.5, QMP150/4.2, QMP180/2.5, QMP180/4.2

Payment & Shipping Terms

Packaging Details: Plywood outer box with bubble bag or paper

Delivery Time: 10-15 working days

Payment Terms: L/C,D/P,T/T,Western Union,Paypal,Credit card

Supply Ability: 28000 sets per week

Gallery

Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room

Product Description

Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room

Description

The table shows the specific parameters of several conventional bottles of different sizes

Technical Specification
Nominal volume(L)	40	70	90	100	120	150	180
Filling capacity(kg)	46.4	81.2	104.4	116	139.2	174	208.8
Designed thickness of cylinder(mm)	5.4	6.3	6.3	6.3	6.3	7.2	7.2
Designed thickness of head(mm)	4.8	5.7	5.7	5.7	5.7	6.5	6.5
Material standard	GB6653-2008
Specified value of chemical ingredients of material	C<0.20% Si<0.35% Mn<1.50% P<0.025% S<0.015% P+SM0.04%
Test of hydraulic pressure	8.4MPa
Test of sealing pressure	5.6MPa

Components

The bottle part is composed of steel cylinder and cylinder valve

Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room 0

Application

Electronic computer room, a data processing center, telecommunications facilities, process control, expensive medical equipment, industrial equipment, library, museum and art gallery, clean room, anechoic chamber, emergency power facilities, flammable liquid storage area, etc.

The place where the fire is easy to happen, like paint-spraying production line, aging-electrical equipment, rolling machine, printing machine, oil switch, oil immersed transformer, melt impregnating tank, tank, large generators, drying equipment, cement pro duction process of pulverized coal, and the ship's engine room, cargo hold, etc.

Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room 1

Package

We always pack it with polyfoam firstly and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.

Automatic FM200 Fire Suppression System Cylinder Without Residue For UPS Room 2
