Home /Products/FM 200 Cylinders/4.2MPa Data Center Fire Protection System Seamless FM200 Cylinder

4.2MPa Data Center Fire Protection System Seamless FM200 Cylinder

1 set
MOQ
negotiation
Price
4.2MPa Data Center Fire Protection System Seamless FM200 Cylinder
Features Gallery Product Description Request A Quote
Features
Specifications
Model No.: QMP32/2.5, QMP40/4.2, QMP52/2.5, QMP70/4.2, QMP100/4.2, QMP106/2.5, QMP120/4.2, QMP147/2.5, QMP150/4.2, QMP180/2.5, QMP180/4.2
Storage Pressure: 4.2MPa
Volume (L): 32，40，52， 70, 100，106，120, 147，150, 180
Internal Diameter: 300, 350, 400
Highlight:

4.2MPa data center fire protection system

,

Data Center Fire Protection System FM200 Cylinder

,

Seamless FM200 Cylinder
Basic Infomation
Place of Origin: China
Brand Name: Air Giant
Certification: CAL,CMA,CNAS,ILAC-MRA,CCC
Model Number: QMP32/2.5, QMP40/4.2, QMP52/2.5, QMP70/4.2, QMP100/4.2, QMP106/2.5, QMP120/4.2, QMP147/2.5, QMP150/4.2, QMP180/2.5, QMP180/4.2
Payment & Shipping Terms
Packaging Details: Plywood outer box with bubble bag or paper
Delivery Time: 10-15 working days
Payment Terms: L/C , D/P, T/T, Western Union, Paypal, Credit card
Supply Ability: 28000 sets per week
Product Description

Cylinder For Non Corrosive FM200 Fire Suppression System Without Pollution In Anechoic Chamber



Description



1. Different shape: tank and cylinder

2. Different model: 8L, 10L, 40L, 70L, 90L etc or custom made

3. Different structure: welded cylinder and seamless cylinder

4. Different material: carbon steel and aluminum





Components



The bottle part is composed of steel cylinder and cylinder valve

4.2MPa Data Center Fire Protection System Seamless FM200 Cylinder 0





Cylinder (L) 40 70 90 100 120 150 180
Nominal volume(L) 40 70 90 100 120 150 180
Filling capacity(kg) 46.4 81.2 104.4 116 139.2 174 208.8
Designed thickness of cylinder(mm) 5.4 6.3 6.3 6.3 6.3 7.2 7.2
Designed thickness of head(mm) 4.8 5.7 5.7 5.7 5.7 6.5 6.5
Material standard GB6653-2008
Specified value of chemical ingredients of material

C<0.20% Si<0.35% Mn<1.50%

P<0.025% S<0.015% P+SM0.04%
Test of hydraulic pressure 8.4MPa
Test of sealing pressure 5.6MPa





Application



• Computer room, communication room, power distribution room, library, archives,

Museum, etc.



• Be used for electrical fire, liquid fire, solid fire, gas fire which can be cut off the gas

source before extinguishing occur, etc.

4.2MPa Data Center Fire Protection System Seamless FM200 Cylinder 1





Package



We always pack it with polyfoam firstly and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.

4.2MPa Data Center Fire Protection System Seamless FM200 Cylinder 2

Tag:

FM 200 Cylinders

fm200 gas cylinder

hfc 227ea cylinder
