Cafss FM200 Automatic Fire Suppression Tube 1m-5m With Signal Feedback Device
Hfc-227ea fire extinguishing tube, with its high efficiency and environmental protection characteristics, has become a major breakthrough in modern fire extinguishing technology. Its unique tube design and high-quality materials ensure the rapid release and stable performance of the extinguishing agent.
Parameters of Fire Suppression Tube
| Model No. | Type of agent |
Amount of agent (g) |
Length of tube (cm) |
Diameter of tube (mm) |
Approximate maximum coverage (cubic meter) |
Working temperature (℃) |
Blasting temperature (℃) |
| AG100H/N |
HFC-227ea / FK-5-1-12 |
250±5 | 100 | 18 | 0.25 | From -40 to 80 | 110±10 |
| AG200H/N | 500±5 | 200 | 18 | 0.5 | From -40 to 80 | 110±10 | |
| AG300H/N | 750±10 | 300 | 18 | 0.75 | From -40 to 80 | 110±10 | |
| AG400H/N | 1000±10 | 400 | 18 | 1 | From -40 to 80 | 110±10 | |
| AG500H/N | 1250±10 | 500 | 18 | 1.25 | From -40 to 80 | 110±10 |
Detachable part-option---Signal feedback device
Installed on the end of the tube, the signal is fed back to the fire extinguishing controller after the fire extinguishing agent is released, and then the fire extinguishing controller lights up the spray door light and sends a linkage signal.
Advantages of Fire Suppression Tube
1. Safe and reliable: Heptafluoropropane fire extinguishing agent is non-toxic, odorless, harmless to human body, safe and reliable.
2. Easy to operate: the fire extinguishing tube is simple in design, easy and convenient to operate, no need for professional skills.
3. Low maintenance cost: no need to replace for long-term use, low maintenance cost.
Functions of Fire Suppression Tube
1. Rapid cooling: the release of fire extinguishing agent can quickly reduce the temperature of the fire, to prevent the fire from further expansion.
2. Extinguish the fire thoroughly: it can penetrate into the fire source, extinguish the fire completely and prevent re-ignition.
3. Protect the environment: Heptafluoropropane fire extinguishing agent is environmentally friendly and harmless, and will not cause pollution to the environment.
Application of Fire Suppression Tube
Heptafluoropropane fire extinguishing hose is suitable for all kinds of enclosed spaces, such as offices, warehouses, laboratories, etc., which provides a strong guarantee for the fire safety of modern society.
Packages of Fire Suppression Tube
We always pack it with polyfoam first and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.
